Full Automatic 3+1 Axis UPVC Window CNC Milling Machine uses professional numerical control system (Taiwan SYNTEC or German PA system), milling and drilling UPVC door and window profiles according to the stored programs. The workbench can be automatically flipped between 90°, 0° and -90° angles without manually moving the UPVC profile.
Our UPVC window CNC milling machine uses a 3.5kw electric spindle to easily mill aluminum alloy profiles, light alloy profiles and UPVC door and window profiles, and the edges of the shaped holes are burr-free and beautiful.
A.C. servo motors are from Taiwan SYNTEC, famous brand, high stability and reliable quality.
Linear guides and ball screws ensure accurate positioning of each movement.
The workbench can be turned over automatically (pneumatic swing angle; optional configuration: servo motor to turn over at any angle ), can complete the processing of three sides of the profile +90°, 0°, and -90° at one time.
Control system of 3+1 Axis UPVC Window CNC Milling Machine , is from Taiwan SYNTEC , very famous brand for CNC processing.
TECHNICAL SPECIFICATION
| Model | LSKX-CNC-1200 | LSKX-CNC-800 |
| Name | UPVC Window CNC Milling Machine | UPVC Window CNC Milling Machine |
| Brand | BLUETEK | BLUETEK |
| Quality Warranty | 2 Years | 2 Years |
| Origin | China | China |
| Certificate | CE | CE |
| Motors Type | Servo Motor | Servo Motor |
| X Axis Process Range | 1200mm | 800mm |
| Y Axis Process Range | 150mm | 150mm |
| Z Axis Process Range | 150mm | 150mm |
| Spindle Speed | 18000 r/min | 18000 r/min |
| Spindle Power | 3.5KW | 3.5KW |
| Total Power | 4.5 KW | 4.5 KW |
| Process Angles | 90° , 0° , -90° | 90° , 0° , -90° |
| Air Pressure | 0.6 -0.8 Mpa | 0.6 -0.8 Mpa |
| Overall Dimension | 1500*1600*1700mm | 1100*1600*1700mm |
| Weight | 800 KG | 600KG |
