MAIN FEATURES
• Aluminium window corner crimping machine is used for window corner joining at 90 ° angle.
• 3 Pairs of tools , can adjust for various specifications of broken bridge aluminum profiles.
• It adopts hydraulic station from Taiwan famous brand.
• Middle location clamp can come up and down, easy to put aluminium frames.
• The crimping tools on two sides are completely synchronized, punching force is even, and the flatness is perfect.
TECHNICAL SPECIFICATION
| Model | LZJ03-130B |
Power Supply | Free Customize |
Motor Power | 1.5 KW |
Rated Oil Pressure | 15 MPa |
Capacity of Oil Box | 30L |
Process Height | 120mm |
Process Width | 120mm |
Crimping Tool Bit Thickness | 3/ 5/ 8 mm |
Total Dimension | 1100*1100*1210mm |
| Gross Weight | 350 KG |
STANDARD ACCESSORIES
| low-voltage apparatus | Schneider, France |
| Air Cylinder | EASUN , Joint Venture |
Solenoid Valve | AirTAC , Taiwan China |
| Air Filter Device | STNC , China |
Motor | Sanyang , China |
| Hydraulic System | Litand , Taiwan China |
